When off-the-shelf hydraulic cylinders can’t meet your application requirements, custom solutions become essential. At Carlson Hydraulics, we’ve been manufacturing custom hydraulic cylinders in Wichita, Kansas since 1953, bringing over seven decades of experience to every project. Our experienced team combines advanced CNC technology with engineering expertise to deliver cylinders tailored to your specific needs—whether you need unique bore sizes, specialized mounting configurations, or performance capabilities beyond standard offerings.
What Makes a Hydraulic Cylinder “Custom”?
Custom hydraulic cylinders are engineered to meet specific requirements that standard catalog products cannot satisfy, from unique dimensions to specialized performance characteristics.
Beyond Standard Specifications
A custom hydraulic cylinder is engineered and built to meet requirements that standard, catalog cylinders simply cannot satisfy. While off-the-shelf cylinders work well for many applications, custom design becomes necessary when your hydraulic system demands specific performance characteristics, unusual dimensions, or specialized features.
Common customization areas include bore sizes and stroke lengths outside standard ranges, specialized mounting configurations like clevis, trunnion, or flange mounts, and custom-made hydraulic components for unique industrial equipment. Material selection plays a crucial role—choosing the right metals and coatings for corrosive environments, extreme temperatures, or specific duty cycles. Pressure ratings can be engineered to exact specifications, and integration features such as custom port locations, integrated valves, or sensor mounting provisions can be incorporated into the custom hydraulic cylinder design.
When Your Application Requires Custom Solutions
Certain industries and applications consistently require a custom hydraulic cylinder manufacturer rather than standard products. In construction equipment, specialized attachments often need cylinders with unique mounting points and stroke requirements that don’t match catalog options. Agricultural machinery operating in harsh field conditions benefits from cylinders designed with specific seal packages and protective coatings. Material handling systems may require precise force control and positioning that demands custom cylinders or specific bore-to-rod ratios.
Mobile equipment working in extreme environments—whether arctic cold or desert heat—needs cylinders built with materials and seals engineered for those conditions. Industrial presses require exact force delivery and consistent performance across millions of cycles, necessitating custom cylinder design and manufacturing processes that ensure reliability. When your hydraulic cylinder needs extend beyond what’s available in standard catalogs, Carlson Hydraulics has the manufacturing resources and design and engineering capabilities to create the solution you need.
Types of Custom Hydraulic Cylinders We Manufacture
Carlson Hydraulics manufactures a complete range of custom cylinder designs, each engineered for specific applications and performance requirements.
Welded Hydraulic Cylinders
Custom made welded hydraulic cylinders represent our primary custom cylinder offering and the foundation of Carlson’s manufacturing expertise. Unlike tie-rod designs, welded cylinders provide increased durability and superior performance for demanding applications. The welded construction creates a stronger cylinder body capable of handling higher pressures and more demanding heavy duty cylinder requirements.
Our custom welded cylinders feature superior seal packages that significantly extend service life compared to standard designs. This makes them ideal for high-performance hydraulic applications where downtime is costly. The welded design proves especially cost-effective for custom bore and stroke combinations, as we can manufacture cylinders to your exact specifications without the constraints of standard tie-rod configurations.
We utilize CNC robotic welding technology to ensure consistent quality across every cylinder we produce. This precision welding process, combined with our rigorous testing protocols, guarantees that each manufactured custom hydraulic cylinder meets the exact performance specifications your application demands. Learn more about our welded cylinder capabilities and how they can solve your toughest hydraulic challenges.
High-Performance Hydraulic Cylinders
When your application demands exceptional reliability under extreme conditions, high-performance hydraulic cylinders become essential. These custom cylinders are engineered for demanding applications where failure isn’t an option—heavy construction equipment, critical industrial processes, or mobile machinery operating in harsh environments.
High-performance features include heavy-duty construction capable of handling extreme operating pressures, enhanced seal packages using premium materials designed for extended service intervals, and precision machining that ensures smooth operation and consistent performance. Material selection for high-performance hydraulic cylinders considers the operating environment, with options for corrosion-resistant coatings, hardened surfaces, and specialized alloys.
Our testing protocols for high-performance cylinders go beyond standard procedures. Every cylinder undergoes hydraulic fluid testing on our test bench, verifying performance at the specified pressure rating before shipment. This ensures the hydraulic cylinders you need will perform reliably when installed in your equipment.
Specialty Custom Cylinders
Beyond standard welded designs, Carlson manufactures several specialty cylinder types for specific applications. Our integrated cartridge valve cylinders incorporate safety valving directly into the cylinder design, making them ideal for applications where load holding and controlled descent are critical safety requirements.
Smart cylinders represent the cutting edge of hydraulic technology, integrating position sensors and monitoring capabilities directly into the cylinder assembly. This allows real-time feedback on cylinder position, pressure, and performance—essential for modern automated systems and predictive maintenance programs.
For weight-sensitive applications, our aluminum cylinders provide excellent strength-to-weight ratios.
Contact Us to discuss your specific cylinder needs
Carlson’s Custom Hydraulic Cylinder Design Process
Our proven design and manufacturing process combines engineering collaboration with precision CNC production to deliver cylinders that meet your exact specifications.
Engineering Expertise Meets Your Requirements
Our custom hydraulic cylinder design process begins with understanding your specific hydraulic requirements. With over 70 years of hydraulic cylinder manufacturing experience, our engineering team has developed a collaborative approach that ensures we capture every critical detail of your application.
The process starts with application analysis—understanding the forces, speeds, operating environment, and duty cycle your cylinder must handle. We then move into design features selection. Material and component specification follows, where we select the right metals, seals, and surface treatments for your operating conditions and industry and application requirements.
Performance testing forms the final phase, where we verify that the finished cylinder meets OEM standards and your specific performance requirements. Our experienced team draws on decades of experience across diverse industries to anticipate potential challenges and engineer solutions that deliver reliable, long-term performance.
Precision Manufacturing to OEM Standards
Custom hydraulic cylinder manufacturing at Carlson Hydraulics relies on state-of-the-art CNC equipment operated by highly trained technicians. Our manufacturing resources include CNC robotic welding systems that deliver consistent, high-quality welds on every cylinder, CNC turning centers for precision machining of rods, pistons, and cylinder tubes, and CNC mills for creating custom hydraulic cylinders and components to exact specifications.
Quality and service define every stage of our manufacturing process. Each cylinder undergoes rigorous testing—with hydraulic fluid on our testing bench to confirm performance at the specified pressure rating. We verify the pressure rating individually for every cylinder, ensuring it meets the exact requirements of your application.
All manufactured custom hydraulic cylinders are backed by our 2-year limited warranty covering manufacturing defects. This warranty reflects our confidence in our design and engineering processes and the quality of every cylinder we produce. When you need cylinder repair or modifications to existing cylinders, we apply the same precision manufacturing standards to ensure reliable performance.
Industry-Leading Custom Hydraulic Cylinder Manufacturing
With over 70 years of American manufacturing experience, Carlson Hydraulics delivers custom cylinders from our Wichita, Kansas facility to industries nationwide.
Wichita, Kansas: American Manufacturing Excellence
Carlson Hydraulics is proudly made in the USA, manufacturing welded hydraulic cylinders from our Wichita, Kansas facility since 1953. Our commitment to American manufacturing means the hydraulic cylinders and components you order are designed, engineered, and built right here in the USA—supporting American jobs and delivering the quality that comes from domestic production.
As a leader in hydraulic cylinder manufacturing, we serve diverse industries with custom solutions. Our agriculture customers rely on us for cylinders that withstand the demanding conditions of farming equipment. Construction equipment manufacturers and repair shops trust Carlson for cylinders that deliver reliable hydraulic power in the toughest job site conditions. Material handling, industrial machinery, transportation, and accessibility equipment applications all benefit from our custom cylinder design capabilities.
From prototype development to full production runs, we handle projects of all sizes. Our lead times typically range from 4 to 10 weeks depending on complexity and order size, providing faster delivery than many competitors while maintaining our commitment to quality manufacturing custom hydraulic solutions.
Design and Manufacturing Capabilities
Our customization capabilities span the full spectrum of hydraulic cylinder specifications. We manufacture custom bore sizes from small hydraulic cylinders for compact equipment to large industrial cylinders for heavy-duty applications. Stroke lengths are tailored to your specifications—whether you need a short-stroke cylinder for precise positioning or an extended stroke for maximum reach.
Pressure ratings are engineered specifically for your application, from lower-pressure designs for general industrial use to high-pressure cylinders for demanding mobile equipment. Custom mounting configurations include clevis mounts, flange mounts, trunnion mounts, and specialized mounting arrangements designed for your specific equipment. Specialized coatings and finishes protect against corrosion, wear, and environmental damage.
Integration with control systems represents another area of capability—we can incorporate ports, valves, and sensor mounting provisions into the cylinder design. These are truly hydraulic cylinders purpose-built™ for your exact needs, not compromised adaptations of standard designs. Our industry-leading custom hydraulic cylinder manufacturing ensures you get precisely the performance and features your application demands.
Custom Cylinder Components and Modifications
Beyond complete cylinder assemblies, our expert hydraulics engineers and machinists build custom components to fit any hydraulic cylinder. We manufacture custom rods machined to precise tolerances and surface finishes, pistons designed for optimal sealing and performance, and cylinder tubes (barrels) built to exact bore specifications and wall thickness requirements. Custom end caps and mounting hardware are designed to match your equipment interfaces, and specialized seal packages are configured for specific operating conditions.
These OEM-quality hydraulic components serve both new builds and retrofit applications for standard or hard-to-find hydraulic cylinders. When existing cylinders need performance upgrades or modifications to match changing application requirements, our team can design and manufacture the custom-made components necessary to extend service life or improve performance.
We also offer modification and upgrade services for existing cylinders. Sometimes a cylinder that no longer meets current needs can be modified rather than completely replaced, saving time and cost. Our hydraulic seal expertise allows us to upgrade seal packages for improved performance and extended service intervals.
All custom components carry our 2-year limited warranty covering manufacturing defects, providing the same quality assurance as our complete cylinder assemblies.
Getting the Custom Hydraulic Cylinders You Need
Understanding your application requirements and specifications is the first step toward designing and manufacturing the perfect custom cylinder for your needs.
Specification Requirements
To provide an accurate quote for your custom hydraulic cylinder, our engineering team needs specific information about your application and hydraulic cylinder needs. Key specifications include operating pressure requirements (maximum and working pressure), bore size and stroke length dimensions, and mounting style (clevis, flange, trunnion, or custom configuration).
Rod diameter and type specifications—whether you need a single-acting or double-acting hydraulic cylinder—are essential. Port size and location must match your hydraulic system connections. Operating environment details help us select appropriate materials and seals: temperature ranges, exposure to chemicals or contaminants, and whether the cylinder operates indoors or outdoors.
Application details provide context that helps us optimize the design: load requirements, cycle frequency, duty cycle classification, and any special performance requirements. Don’t worry if you’re unsure about technical specifications—our experienced team helps translate application needs into engineering specifications, ensuring you get exactly the cylinder your application requires.
From Quote to Delivery
Our process begins with fast quote turnaround from our engineering team. We review your specifications and application details to provide accurate pricing and delivery estimates. If needed, we engage in collaborative design refinement to optimize the cylinder configuration for performance, reliability, and cost-effectiveness.
Once the design is finalized and your order is placed, manufacturing typically takes 4 to 10 weeks depending on complexity and order size. Throughout production, we maintain quality standards with our rigorous testing protocols—every cylinder is tested with compressed air and hydraulic fluid before shipment.
Quality testing verifies that each cylinder meets the specified pressure rating and performs according to design requirements. For ongoing support, our team is available to assist with troubleshooting, maintenance recommendations, and future cylinder needs.
Contact Us to discuss your specific cylinder needs
Partner with Carlson Hydraulics for Custom Hydraulic Solutions
Custom hydraulic cylinders solve problems that standard, off-the-shelf cylinders simply cannot address. When your application demands precise specifications, unusual configurations, or performance beyond catalog offerings, custom design and manufacturing become essential. Carlson Hydraulics brings together engineering expertise, precision manufacturing capabilities, and over 70 years of experience to deliver the custom solutions you need.
Our combination of advanced CNC equipment, rigorous testing protocols, and experienced team ensures that every custom cylinder meets exacting standards. As a proudly American manufacturer based in Wichita, Kansas, we deliver the quality and reliability that comes from domestic production, supporting your operations with responsive service and comprehensive warranty coverage.
Whether you need welded cylinders, custom designs, high-performance double-acting cylinders for extreme conditions, or specialty configurations with integrated components, Carlson has the custom manufacturing capabilities to deliver cylinders that match your specific needs. Our commitment to quality and service extends from initial design consultation through manufacturing, testing, and long-term support.
Ready to discuss your custom hydraulic cylinder requirements? Contact Carlson Hydraulics today. Our engineering team is ready to help you design the perfect solution for your application, delivering the precision-engineered cylinders your equipment demands.
